SX1239IMLTRT SEMTECH ELECTRONICS LTD. SX1239IMLTRT real image SX1239IMLTRT label picture SX1239IMLTRT label picture 2
Same model may have multiple batches, images only for reference.
SX1239IMLTRT SEMTECH ELECTRONICS LTD. SX1239IMLTRT real image SX1239IMLTRT label picture SX1239IMLTRT label picture 2
SX1239IMLTRT SEMTECH ELECTRONICS LTD. SX1239IMLTRT real image SX1239IMLTRT label picture SX1239IMLTRT label picture 2
Same model may have multiple batches, images only for reference.

SX1239IMLTRT

Part No SX1239IMLTRT
Manufacturer Semtech Corporation
Catalog RF Receivers
Description RF RX FSK/GFSK 433/868MHZ 24QFN
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Receivers
Mfr Semtech Corporation
Series TrueRF™
Package Tape & Reel
Product Status Active
Frequency 433MHz, 868MHz, 915MHz
Sensitivity -120dBm
Data Rate (Max) 300kbps
Modulation or Protocol FSK, GFSK, GMSK, MSK, OOK
Applications AMR, Home Automation, Security
Current - Receiving 16mA
Data Interface PCB, Surface Mount
Antenna Connector PCB, Surface Mount
Voltage - Supply 1.8V ~ 3.6V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 24-VQFN Exposed Pad
Supplier Device Package 24-QFN (5x5)
Base Product Number SX1239
Standard Package 3,000 pcs
MSL Level 2 (1 Year)
ECCN EAR99
HTSUS 8542.39.0001
Win Source Part Number 843762-SX1239IMLTRT
Ultra Librarian 3D Model Ultra Librarian SX1239IMLTRT CAD Model

Description

The 843762-SX1239IMLTRT is a TrueRF™ RF receiver from Semtech Corporation.

  • Applications: AMR, home automation, and security systems
  • Frequencies: 433MHz, 868MHz, and 915MHz
  • Sensitivity: -120dBm
  • Data Rate: Up to 300kbps
  • Modulation Protocols: FSK, GFSK, GMSK, MSK, and OOK
  • Voltage Range: 1.8V to 3.6V
  • Mounting Type: Surface Mount
  • Package: 24-VQFN exposed pad
  • Product Status: Active
  • Series: TrueRF™
