3402.0009.22

Part No 3402.0009.22
Manufacturer Schurter Inc.
Catalog Fuses
Description FUSE BOARD MNT 1A 63VAC/VDC 2SMD
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Circuit Protection
Manufacturer Schurter Inc.
Packaging Reel - TR
Status Active
Fuse Type Board Mount (Cartridge Style Excluded)
Current Rating 1A
Voltage Rating - AC 63V
Voltage Rating - DC 63V
Response Time Fast
Mounting SMD (SMT)
Breaking Capacity @ Rated Voltage 50A
Nominal Melting - I2t 0.078
Approvals cURus
Temperature Range - Operating -55°C to 125°C
Dimension 0.291" L x 0.122" W x 0.102" H (7.40mm x 3.10mm x 2.60mm)
Win Source Part Number 197650-3402.0009.22
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 3402.0009.22 CAD Model

Description

Product Description

The 3402.0009.22 is a high-quality electronic component suitable for various applications requiring reliable performance and longevity. Crafted with precision, this component ensures optimal efficiency and seamless integration into your projects.

Applications

  • Industrial Automation Systems
  • Robotics
  • Consumer Electronics
  • Automotive Electronics

Features and Benefits

  • High Durability: Built to withstand demanding conditions, ensuring longevity.
  • Excellent Performance: Provides consistent and accurate performance.
  • Compact Design: Easy to integrate into tight spaces within your device or system.

Additional Details

This product is designed to meet industry standards, ensuring compatibility and reliability across a wide range of applications.
