The SSW series connector is a receptacle type connector with 64 forked contacts.

• Connector Type: Receptacle
• Contact Type: Forked
• Number of Contacts: 64
• Fastening Type: Push-pull
• Termination: Solder
• Insulation Material: Liquid Crystal Polymer (LCP)
• Insulation Color: Black
• Pitch (Mating): 0.100'' (2.54mm)
• Contact Finish (Mating): Gold with a thickness of 20.0µin (0.51µm)
• Contact Finish (Post): Gold with a thickness of 3.00µin (0.076µm)
• Current Rating: 4.7A per contact
• Temperature Range: -55°C ~ 125°C
• Application: Board-to-board or cable style connections
• Package: Bulk
• Insulation Height: 0.335'' (8.51mm)
• Row Spacing (Mating): 0.100'' (2.54mm)
• Material Flammability Rating: UL94 V-0
