Products specifications

Reference Date Code 2016+
Reference case SOD923
Manufacturer Rohm Semiconductor
Manufacturer Homepage www.rohm.com
Win Source Part Number 720046-RB520CM-30
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RB520CM-30 CAD Model

Description

The RB520CM-30 is a Schottky Barrier Diode manufactured by Rohm Semiconductor. It is designed for high-speed switching and low forward voltage drop applications. This diode is commonly used in rectification, freewheeling, and protection circuits. The RB520CM-30 features a small surface mount package, making it suitable for high-density circuit designs.

Applications

  • Rectification circuits
  • Freewheeling diodes
  • Protection circuits
  • DC-DC converters
  • Reverse polarity protection

Features

  • Schottky Barrier Diode
  • Low forward voltage drop (Vf)
  • High-speed switching
  • Small surface mount package (SOD-323)
  • Low leakage current
  • RoHS Compliant

Benefits

  • Reduced power losses due to low forward voltage drop.
  • Fast switching speeds for improved performance.
  • Compact size for high-density circuit designs.
  • Improved efficiency in power conversion applications.
  • Reliable performance in various operating conditions.

Additional Details

The RB520CM-30's low forward voltage drop minimizes power losses when the diode is conducting, thereby improving efficiency. The high-speed switching capability allows for fast response times in switching circuits. The small SOD-323 package allows for compact circuit designs, making it ideal for portable devices and other space-constrained applications. This diode is commonly used in rectification circuits to convert AC voltage to DC voltage. It is also used as a freewheeling diode to protect inductive loads from voltage spikes. The RB520CM-30 is a versatile and efficient diode suitable for a wide range of applications.

The low leakage current of the diode ensures minimal current flow when the diode is reverse biased, further improving efficiency. The RoHS compliance ensures that the device is environmentally friendly and meets regulatory requirements. This diode is designed to provide reliable and consistent performance in various operating conditions.
