RB160VAM-40TR Rohm Semiconductor RB160VAM-40TR real image4997
Same model may have multiple batches, images only for reference.
RB160VAM-40TR Rohm Semiconductor RB160VAM-40TR real image4997
RB160VAM-40TR Rohm Semiconductor RB160VAM-40TR real image4997
Same model may have multiple batches, images only for reference.

RB160VAM-40TR

Part No RB160VAM-40TR
Manufacturer Rohm Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 40V 1A TUMD2M
Datasheet
RB160VAM-40TR Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 550mV @ 700mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 50μA @ 40V
Mounting SMD (SMT)
Case / Package TUMD2M
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 108754-RB160VAM-40TR
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RB160VAM-40TR CAD Model

Description

The RB160VAM-40TR is a Schottky diode with a maximum reverse voltage of 40V and an average rectified current of 1A.

  • Maximum Reverse Voltage: 40V
  • Average Rectified Current: 1A
  • Forward Voltage: 550mV @ 700mA
  • Reverse Leakage Current: 50μA @ 40V
  • Case/Package: TUMD2M
  • Mounting: Surface mount technology (SMT)
  • Operating Temperature: Up to 150°C
  • Recovery Speed: Fast recovery, 200mA (Io)
  • Packaging: Reel
  • Popularity: Medium
