RB160M-60TR Rohm Semiconductor RB160M-60TR Real Image RB160M-60TR real image4996 RB160M-60TR Real Image1 RB160M-60TR Real Image2
Same model may have multiple batches, images only for reference.
RB160M-60TR Rohm Semiconductor RB160M-60TR Real Image RB160M-60TR real image4996 RB160M-60TR Real Image1 RB160M-60TR Real Image2
RB160M-60TR Rohm Semiconductor RB160M-60TR Real Image RB160M-60TR real image4996 RB160M-60TR Real Image1 RB160M-60TR Real Image2
Same model may have multiple batches, images only for reference.

RB160M-60TR

Part No RB160M-60TR
Manufacturer Rohm Semiconductor
Catalog Diodes, Rectifiers - Single
Description DIODE SCHOTTKY 60V 1A PMDU
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer Rohm Semiconductor
Packaging Reel - TR
Status Not For New Designs
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 60V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 550mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 50μA @ 60V
Capacitance @ Vr, F 40pF @ 10V, 1MHz
Mounting SMD (SMT)
Case / Package PMDU
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 027113-RB160M-60TR
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Family Name RB160M-60
Introduction Date January 05, 2004
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2019
Ultra Librarian 3D Model Ultra Librarian RB160M-60TR CAD Model

Description

The RB160M-60TR is a Schottky diode from Rohm Semiconductor.

  • Maximum Reverse Voltage: 60V
  • Average Rectified Current: 1A
  • Forward Voltage: 550mV @ 1A
  • Reverse Leakage Current: 50μA @ 60V
  • Capacitance @ Vr, F: 40pF @ 10V, 1MHz
  • Packaging: Reel
  • Mounting: SMD (SMT) technology
  • Case/Package: PMDU
  • Fast Recovery: 200mA (Io)
  • Operating Temperature: 150°C (Max)
  • Category: Discrete Semiconductor Products
  • Status: Not available for new designs
  • Supply and Demand Status: Sufficient
