Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Categories Cable Assemblies
Manufacturer Amphenol RF Division
Status Active
Gender Male to Male
Style SMPM to SMPM
1st Connector SMPM Male Plug
2nd Connector SMPM Male Plug
Length 6.000" (152.40mm)
Cable Type 0.085" Semi-Rigid Cable
Impedance 50 Ohm
Maximum Input Frequency 20GHz
Win Source Part Number 293433-RF2658
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF2658 CAD Model

Description

The 293433-RF2658 from Amphenol RF Division is a male to male cable assembly that is designed for use in a variety of applications.

  • Length: 6.000" (152.40mm)
  • Cable: 0.085" semi-rigid cable
  • Impedance: 50 Ohm
  • Maximum Input Frequency: 20GHz
  • Category: Cable Assemblies
  • Status: active
  • Package Contains: 1 pc
