RF2460 RF Micro Devices
Same model may have multiple batches, images only for reference.

RF2460

Part No RF2460
Manufacturer RF Micro Devices
Catalog Coaxial Connectors (RF)
Description CONN PSMP JACK STR 50 OHM PCB
Datasheet
RF2460 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Amphenol RF Division
Packaging Reel - TR
Status Active
Connector Style PSMP
Connector Type Jack, Male Pin
Contact Termination Solder
Shield Termination Solder
Impedance 50 Ohm
Mounting Through Hole
Fastening Type Snap-On
Maximum Input Frequency 10GHz
Features Limited Detent
Housing Color Gold
Body Material Brass
Body Finish Gold
Center Contact Plating Gold
Dielectric Material Polyetheretherketone (PEEK)
Temperature Range - Operating -65°C to 165°C
Center Contact Material Brass
Voltage Rating 480V
Mating Cycles 100
Win Source Part Number 293381-RF2460
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian RF2460 CAD Model

Description

The Amphenol RF Division RF2460 is a high-quality PSMP jack connector that features limited detent and male pin.

  • Voltage Rating: 480V
  • Impedance: 50 Ohm
  • Mounting: through-hole mounting
  • Material: brass
  • Finish: gold finish
  • Category: connectors and interconnects
  • Supply and Demand Status: limited
