RF2314TR7 RF Micro Devices RF2314TR7 label picture
Same model may have multiple batches, images only for reference.
RF2314TR7 RF Micro Devices RF2314TR7 label picture
RF2314TR7 RF Micro Devices RF2314TR7 label picture
Same model may have multiple batches, images only for reference.

RF2314TR7

Part No RF2314TR7
Manufacturer RF Micro Devices
Catalog RF Amplifiers
Description IC AMP HBT GAAS 2.5GHZ SOT23-5
Datasheet
RF2314TR7 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer RF Micro Devices
Packaging Reel - TR
Status Active
Frequency 150MHz to 2.5GHz
P1dB -2dBm (0.6mW) to 1dBm (1.3mW)
Gain 11dB to 14dB
Noise Figure 1.4dB
RF Type ISM
Supply Voltage - Operating 2.7 V to 6 V
Operating Supply Current 9mA to 16mA
Test Frequency 900MHz
Case / Package SOT-5
Win Source Part Number 062485-RF2314TR7
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian RF2314TR7 CAD Model

Description

The RF2314TR7 is an RF amplifier from RF Micro Devices.

  • Test Frequency: 900MHz
  • Frequency Range: 150MHz to 2.5GHz
  • Gain: 11dB to 14dB
  • Noise Figure: 1.4dB
  • P1dB: -2dBm (0.6mW) to 1dBm (1.3mW)
  • RF Type: ISM
  • Category: RF/IF and RFID
  • Status: Active
  • Case/Package: SOT-5
  • Operating Supply Voltage: 2.7V to 6V
  • Operating Supply Current: 9mA to 16mA
  • Supply and Demand Status: Balanced
