Same model may have multiple batches, images only for reference.

RF1005

Name: RF1005
Brand: RF Micro Devices
SKU: 293091
Availability: InStock
Rating: 4.85 (5 reviews)

Get a Quote

Part No	RF1005
Manufacturer	RF Micro Devices
Catalog	Coaxial Connectors (RF)
Description	CONN UHF RCPT STR SOLDER
Datasheet	RF1005 Datasheet
Sample
Rohs State
ECAD Module
	Add to BOM List New List Existing List This product has been added to your list. List name
Need Help

Products specifications Report Issue?

Categories	Connectors, Interconnects
Manufacturer	Amphenol RF Division
Packaging	Bulk
Status	Active
Connector Style	UHF
Connector Type	Receptacle, Female Socket
Contact Termination	Solder Cup
Shield Termination	Solder
Impedance	Non-Constant
Mounting	Panel Mount
Mounting Feature	Flange
Fastening Type	Threaded
Maximum Input Frequency	300MHz
Housing Color	Silver
Body Material	Zinc Die Cast
Body Finish	Nickel
Center Contact Plating	Silver
Dielectric Material	Polybutylene Terephthalate (PBT), Polyester
Center Contact Material	Brass
Voltage Rating	500V
Win Source Part Number	293091-RF1005
Popularity	Medium
Supply and Demand Status	Limited
Ultra Librarian 3D Model	Ultra Librarian RF1005 CAD Model

Description

The Amphenol RF Division 293091-RF1005 is an active electronic component with a medium popularity. This component is a UHF connector type with a receptacle, female socket and a threaded fastening type.

Win Source Part Number: 293091-RF1005
Connector Type: UHF
Voltage Rating: 500V
Maximum Input Frequency: 300MHz
Housing Color: silver
Body Material: zinc die cast
Contact Termination: solder cup
Connector Style: UHF
Shield Termination: solder
Mounting Feature: flange
Body Finish: nickel
Center Contact Material: brass with silver plating
Dielectric Material: Polybutylene Terephthalate (PBT), Polyester
