The Realtek RTL8367SB-CG is a highly integrated 7-port Gigabit Ethernet switch controller, designed for use in cost-effective and high-performance switching applications.
Applications:
- Unmanaged Gigabit Ethernet Switches: Used in unmanaged switches for small and medium-sized networks.
- Lightly Managed Switches: Implemented in switches with basic management features like VLAN support.
- SOHO (Small Office/Home Office) Networks: Provides high-speed connectivity for SOHO environments.
- Desktop Switches: Used in desktop switches for connecting multiple devices.
- Industrial Ethernet Applications: Can be adapted for use in some industrial Ethernet applications where basic switching functionality is needed.
Features:
- 7-Port Gigabit Ethernet Switch: Offers seven 10/100/1000 Mbps Ethernet ports for flexible connectivity.
- Non-Blocking Architecture: Provides wire-speed forwarding performance across all ports.
- VLAN Support: Supports VLAN tagging and port-based VLANs for network segmentation.
- QoS (Quality of Service): Offers basic QoS features for traffic prioritization.
- Auto-MDI/MDIX: Automatically detects and configures MDI/MDIX ports, simplifying installation.
- Energy-Efficient Ethernet (EEE): Supports Energy-Efficient Ethernet (EEE) to reduce power consumption.
Benefits:
- High-Speed Connectivity: Provides Gigabit Ethernet connectivity for fast data transfer.
- Easy to Deploy: Auto-MDI/MDIX and plug-and-play operation simplify deployment.
- Energy Efficient: EEE support helps reduce power consumption, saving energy costs.
- Cost-Effective: Offers a cost-effective solution for building high-performance Ethernet networks.
Additional Details:
The RTL8367SB-CG is generally packaged in a QFP (Quad Flat Package). It requires a 3.3V power supply for I/O and a lower voltage for the core. It supports IEEE 802.3az Energy-Efficient Ethernet. The operating temperature range is typically 0°C to 70°C. Consult the Realtek datasheet for more precise details.
