R121630003 Radiall USA, Inc. – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

R121630003

Part No R121630003
Manufacturer Radiall USA, Inc.
Catalog Coaxial Connectors (RF) - Assemblies
Description SSMA Connector Jack, Female Socket 50 Ohms Through Hole Solder
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mfr Radiall USA, Inc.
Packaging Bulk
Connector Style SSMA
Connector Type Jack, Female Socket
Contact Termination Solder
Shield Termination Solder
Impedance 50 Ohms
Mounting Type Through Hole
Fastening Type Threaded
Frequency - Max 18 GHz
Number of Ports 1
Features Hermetically Sealed
Housing Color Gold
Center Contact Material Beryllium Copper
Body Material Stainless Steel
Body Finish Gold
Center Contact Plating Gold
Dielectric Material Polytetrafluoroethylene (PTFE)
Temperature Range - Operating -55°C ~ 155°C
Voltage Rating 250 V
Mating Cycles 500
Base Product Number R12163
RoHS Status ROHS3 Compliant
MSL Level Not Applicable
ECCN EAR99
HTSUS 8536.69.4010
Win Source Part Number 1480657-R121630003
Ultra Librarian 3D Model Ultra Librarian R121630003 CAD Model
