The PE4248 is a high-performance SPDT (Single Pole Double Throw) RF switch from Peregrine Semiconductor. This switch is specifically designed for high-power applications requiring low insertion loss, high isolation, and excellent linearity.

Applications

• High-power switching in cellular infrastructure
• Test and measurement equipment
• Public safety radio
• Wireless infrastructure
• General-purpose RF switching applications

Features

• High power handling: up to +36 dBm
• Low insertion loss: 0.4 dB at 3 GHz
• High isolation: 30 dB at 3 GHz
• Single positive supply: 2.7 V to 5.5 V
• UltraCMOS® process technology
• Compact QFN package

Benefits

• Robust performance in high-power applications, ensuring signal integrity and reliability.
• Enhanced system efficiency with low insertion loss, maximizing signal strength and minimizing power loss.
• Reduced interference and crosstalk with high isolation, ensuring signal purity.
• Simplified system design with a single positive supply, reducing component count and complexity.
• High reliability and performance with UltraCMOS® technology.
• Space-saving design with a compact QFN package.

Additional Details

The PE4248 operates over a broad frequency range, typically from 100 MHz to 6 GHz, making it versatile for a wide range of RF applications. It is fabricated using Peregrine's UltraCMOS® process technology, ensuring high performance and reliability. The switch is available in a compact QFN package, making it suitable for space-constrained designs. The high power handling capability makes it ideal for applications where the RF signal strength is substantial. The high IIP3 ensures that the switch introduces very little distortion, which is critical in applications where signal fidelity is paramount. The low insertion loss helps to maintain signal strength, while the high isolation prevents unwanted signals from leaking through.
