HC1E-HP-AC6V Real Image
Same model may have multiple batches, images only for reference.

HC1E-HP-AC6V

Part No HC1E-HP-AC6V
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GENERAL PURPOSE SPDT 5A 6V
Datasheet
HC1E-HP-AC6V Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer Panasonic Electric Works
Packaging Bulk
Status Obsolete(EOL)
Relay Type General Purpose
Coil Type Non Latching
Coil Current 200mA
Coil Voltage 6VAC
Contact Form SPDT (1 Form C)
Contact Rating (Current) 5A
Switching Voltage 250VAC - Max
Turn On Voltage (Max) 4.8 VAC
Turn Off Voltage (Min) 1.8 VAC
Operate Time 10ms
Release Time 10ms
Features Sealed - Amber
Mounting Through Hole
Termination Style PC Pin
Coil Power 1.2 VA
Temperature Range - Operating -40°C to 60°C
Win Source Part Number 204583-HC1E-HP-AC6V
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian HC1E-HP-AC6V CAD Model

Description

The Panasonic Electric Works component is a general-purpose relay that is suitable for various electronic applications. It has a medium popularity rating and a limited supply and demand status. The component is designed to meet the specific needs of electronic devices, making it a perfect fit for various applications. The component is now considered obsolete.
