DSP1-DC24V-R-F Panasonic – Price, Stock & Datasheet
Same model may have multiple batches, images only for reference.

DSP1-DC24V-R-F

Part No DSP1-DC24V-R-F
Manufacturer Panasonic
Catalog Power Relays, Over 2 Amps
Description RELAY GEN PURPOSE DPST 5A 24V
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Mounting Type Through Hole
Coil Voltage 24VDC
Contact Form DPST-NO/NC (1 Form A, 1 Form B)
Contact Rating (Current) 5 A
Switching Voltage 250VAC, 125VDC - Max
Load - Max Switching 1500VA, 625W
Coil Current 12.5 mA
Coil Type Non Latching
Features Reverse Coil Polarity
Termination Style PC Pin
Seal Rating Sealed - Fully
Must Operate Voltage 19.2 VDC
Must Release Voltage 2.4 VDC
Operate Time 10 ms
Release Time 5 ms
Temperature Range - Operating -40°C ~ 65°C
Contact Material Silver Tin Oxide (AgSnO)
Approval Agency cURus, VDE
Relay Type General Purpose
Package Tube
Supply and Demand Status Shortage
Win Source Part Number 1548902-DSP1-DC24V-R-F
Ultra Librarian 3D Model Ultra Librarian DSP1-DC24V-R-F CAD Model

Description

N
