Same model may have multiple batches, images only for reference.
1393280-5 Real Image
Same model may have multiple batches, images only for reference.

1393280-5

Part No 1393280-5
Manufacturer TE Connectivity
Catalog Power Relays, Over 2 Amps
Description RELAY AUTO SPST-NO 30A 12V
Datasheet
1393280-5 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Relays
Manufacturer TE Connectivity Potter & Brumfield Relays
Packaging Bulk
Status Active
Relay Type Automotive
Coil Type Non Latching
Coil Current 47.2mA
Coil Voltage 12VDC
Contact Form SPST-NO (1 Form A)
Contact Rating (Current) 30A
Switching Voltage 12VDC - Nom
Turn On Voltage (Max) 6.9 VDC
Turn Off Voltage (Min) 1.5 VDC
Operate Time 3ms
Release Time 1.5ms
Mounting Through Hole
Termination Style PC Pin
Coil Power 567 mW
Coil Resistance 254 Ohms
Temperature Range - Operating -40°C to 105°C
Win Source Part Number 1001442-1393280-5
Popularity Medium
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 1393280-5 CAD Model

Description

The TE Connectivity Potter & Brumfield Relays 1393280-5 is a single-pole, single-throw (SPST-NO) automotive relay.

  • Contact Rating: 30A
  • Switching Voltage: 12VDC
  • Coil Voltage: 12VDC
  • Coil Resistance: 254 Ohms
  • Operate Time: 3ms
  • Release Time: 1.5ms
  • Mounting: Through-Hole
  • Packaging: Bulk
  • Operating Temperature Range: -40°C to 105°C
  • Application: Automotive
