Same model may have multiple batches, images only for reference.
DA4X106U0R Real Image
Same model may have multiple batches, images only for reference.

DA4X106U0R

Part No DA4X106U0R
Manufacturer Panasonic
Catalog Bridge Rectifiers
Description BRIDGE RECT 1P 80V 100MA MINI4
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Discrete Semiconductor Products - Diodes - Bridge Rectifiers
Mfr Panasonic
Package Tape & Reel
Product Status Discontinued
Diode Type Single Phase
Technology Standard
Voltage - Peak Reverse (Max) 80 V
Current - Average Rectified (Io) 100 mA
Voltage - Forward (Vf) (Max) @ If 1.2 V @ 100 mA
Current - Reverse Leakage @ Vr 100 nA @ 80 V
Temperature Range - Operating 150°C (TJ)
Mounting Type Surface Mount
Package / Case SC-61AB
Supplier Device Package Mini4-G4-B
Base Product Number DA4X106
Standard Package 3,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8541.10.0070
Win Source Part Number 845605-DA4X106U0R
Ultra Librarian 3D Model Ultra Librarian DA4X106U0R CAD Model

Description

The 845605-DA4X106U0R is a single-phase bridge rectifier diode designed for various applications from Panasonic.

  • Forward Voltage: 1.2V @ 100mA
  • Peak Reverse Voltage: 80V
  • Current Rating: 100mA
  • Reverse Leakage Current: 100nA @ 80V
  • Mounting Type: Surface Mount
  • Package: SC-61AB
  • Maximum Operating Temperature: 150°C
  • Package Type: Tape and Reel
  • Standard Package Quantity: 3,000 pcs
