Same model may have multiple batches, images only for reference.
AN7125 Real Image
Same model may have multiple batches, images only for reference.

AN7125

Part No AN7125
Manufacturer Panasonic
Catalog Linear - Amplifiers - Audio
Description IC AUDIO AMP 2CH 10W SIL-12 W/FN
Datasheet
AN7125 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Panasonic Electronic Components
Packaging Bulk
Status Obsolete(EOL)
Type Class AB
Output Type 2-Channel (Stereo)
Max Output Power x Channels @ Load 12W x 2 @ 4 Ohm
Supply Voltage - Operating 6 V to 18 V
Features Mute, Short-Circuit and Thermal Protection, Standby
Mounting Through Hole
Temperature Range - Operating -25°C to 75°C (TA)
Case / Package 12-SIL
Dimension 12-SIP + Tab
Win Source Part Number 1016723-AN7125
Popularity Medium
Supply and Demand Status Balance
Ultra Librarian 3D Model Ultra Librarian AN7125 CAD Model

Description

The AN7125 is a class AB audio power amplifier IC manufactured by Panasonic Electronic Components.

  • Type: Class AB Audio Power Amplifier
  • Standby Mode: Yes
  • Output: 2-Channel (Stereo)
  • Output Power: 12W x 2 @ 4 Ohm
  • Case/Package: 12-SIL
  • Dimension: 12-SIP + Tab
  • Status: Obsolete (EOL)
  • Popularity: Medium
  • Temperature Range: -25°C to 75°C (TA)
  • Operating Voltage: 6V to 18V
  • Mounting: Through-Hole
