Category Discrete Semiconductor Products - Diodes - Rectifiers - Single Diodes
Mfr ON Semiconductor
Series *
Package Bulk
Product Status Active
Standard Package 1 pcs
MSL Level 1 (Unlimited)
REACH Status Vendor Undefined
ECCN EAR99
HTSUS 8541.10.0080
Win Source Part Number 663805-SB40-05J
Ultra Librarian 3D Model Ultra Librarian SB40-05J CAD Model

Description

Product Overview: SB40-05J - Schottky Barrier Rectifier

The SB40-05J from ON Semiconductor is a high-performance Schottky Barrier Rectifier designed for applications requiring low voltage drop and high efficiency. This rectifier is ideal for use in power supply operations, particularly in compact and energy-sensitive electronics where efficiency is paramount.

Key Features

  • Voltage Rating: The SB40-05J has a forward voltage rating of 40V, making it suitable for a range of low voltage applications.
  • Current Capacity: It boasts a forward current capacity of 0.5A, providing sufficient throughput for moderate power requirements.
  • Low Forward Voltage Drop: The device features a low forward voltage drop, which enhances system efficiency by minimizing power loss during operation.
  • High Surge Capability: With its excellent surge handling capability, the SB40-05J can withstand transient excess currents, ensuring reliability and longevity.
  • Thermal Performance: Optimized for thermal performance, the rectifier can maintain stable operation across a wide temperature range.

Applications

The SB40-05J Schottky Barrier Rectifier is widely used in various applications, including:

  • Switching power supplies
  • Converters
  • Free-wheeling diodes
  • Polarity protection devices
  • Power management systems

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the SB40-05J is no exception. It is manufactured to the highest standards to ensure consistent performance and reliability. The device is RoHS compliant, reflecting ON Semiconductor's dedication to environmental responsibility.

Technical Specifications

Parameter Value Package / Case DO-204AL (DO-41) Max Repetitive Reverse Voltage (Vrrm) 40V Average Rectified Forward Current (Io) 0.5A Forward Voltage Drop (Vf) Typically 0.385V at 0.5A Operating Temperature Range -65°C to +125°C

With its robust design and versatile application range, the SB40-05J from ON Semiconductor is an excellent choice for designers looking to enhance the efficiency and reliability of their power management systems.
