Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Configuration 1 Pair Common Cathode
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 50V
Current - Average Rectified (Io) (per Diode) 500mA
Voltage - Forward (Vf) (Max) @ If 550mV @ 500mA
Speed(Frequency) Fast Recovery = 200mA (Io)
Reverse Recovery Time (trr) 10ns
Current - Reverse Leakage @ Vr 50μA @ 25V
Operating Temperature - Junction -55°C to 125°C
Mounting SMD (SMT)
Case / Package 3-CP
Win Source Part Number 028029-SB05W05C-TB-E
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Balance
Family Name SB05W05C
Introduction Date September 02, 1998
ECCN EAR99
Halogen Free Compliant
Estimated EOL Date 2023
Ultra Librarian 3D Model Ultra Librarian SB05W05C-TB-E CAD Model

Description

The ON Semiconductor SB05W05C-TB-E is a high-performance Schottky barrier diode designed for applications requiring fast switching and low forward voltage drop. This diode is part of ON Semiconductor's extensive range of semiconductor components known for their reliability and efficiency. The SB05W05C-TB-E is particularly suited for high-frequency inverters, DC-DC converters, and freewheeling diodes in a variety of electronic devices.

Key Features

  • Low Forward Voltage Drop: The device features a low forward voltage drop, which results in lower power losses and improved efficiency in your circuit designs.
  • High Current Capacity: With a forward continuous current rating of 0.5 A, this diode can handle significant current, making it suitable for a wide range of applications.
  • Fast Switching Speed: Its fast switching capability ensures that the diode can operate efficiently at high frequencies, which is essential for modern electronic equipment.
  • Low Leakage Current: The SB05W05C-TB-E has a low reverse leakage current, thereby reducing power consumption when in the off-state.
  • Surface Mount Package: The diode comes in a convenient SOD-323 package, which is ideal for space-constrained applications and allows for easy integration into surface mount technology (SMT) processes.

Applications

The ON Semiconductor SB05W05C-TB-E is versatile and can be used in a variety of applications, including:

  • Power supply circuits
  • Automotive systems
  • Portable devices
  • Power management solutions
  • High-frequency inverters
  • DC-DC converters

Specifications

Parameter Value Package SOD-323 Forward Continuous Current (I<sub>F) 0.5 A Maximum Reverse Voltage (V<sub>R) 40 V Forward Voltage Drop (V<sub>F) 0.38 V @ I<sub>F = 0.5 A Reverse Leakage Current (I<sub>R) 2 µA @ V<sub>R = 10 V

For engineers and designers looking for a Schottky diode that offers high efficiency and reliability, the ON Semiconductor SB05W05C-TB-E is an excellent choice that meets a broad range of requirements.
