The ON Semiconductor NLU1GT04MUTCG is a high-performance, single-gate inverter designed for optimal efficiency and integration in a wide range of applications. Part of the TinyLogic UHS (Ultra High-Speed) series, this inverter is fabricated with advanced silicon gate CMOS technology to achieve operating speeds similar to LSTTL, with the low power consumption of standard CMOS integrated circuits.

Key Features

• High-Speed Operation: The NLU1GT04MUTCG is capable of operating at high speeds, which makes it suitable for fast signal processing applications.
• Low Power Consumption: Despite its high-speed capabilities, this inverter maintains a low power profile, conserving energy in sensitive electronic devices.
• Space-Saving Design: Housed in a micro-miniature, thin-shrink small outline package (µTSSOP), it is ideal for space-constrained applications.
• Wide Operating Voltage Range: It can operate over a broad voltage range from 1.65V to 5.5V, accommodating various levels of signal and power requirements.
• High Noise Immunity: The NLU1GT04MUTCG exhibits high noise immunity, ensuring stable operation even in electrically noisy environments.
• Lead-Free and RoHS Compliant: This product is lead-free and complies with the RoHS directive, making it environmentally friendly and suitable for use in all regions with strict environmental standards.

Applications

The versatility of the ON Semiconductor NLU1GT04MUTCG allows it to be used in a variety of applications, including:

• Servers
• Personal Computers
• Networking Equipment
• Portable Devices
• Signal Processing
• Logic Level Translation
• Any application requiring high-speed CMOS operation

Product Summary

The ON Semiconductor NLU1GT04MUTCG is a testament to the company's commitment to providing advanced semiconductor solutions. Its high-speed operation, low power consumption, and compact form factor make it an excellent choice for designers looking to optimize their electronic systems. Whether it's for consumer electronics, industrial applications, or communication infrastructure, this TinyLogic UHS inverter is engineered to deliver reliable performance in a miniature package.
