Products specifications Report Issue?

Category Integrated Circuits (ICs) - Clock/Timing - Clock Buffers, Drivers
Mfr ON Semiconductor
Package Tray
Product Status Obsolete
Type Fanout Buffer (Distribution), Data
Number of Circuits 1
Input CML, LVCMOS, LVDS, LVTTL, NECL, PECL, RSECL
Output RSECL, RSNECL, RSPECL
Frequency - Max 12 GHz
Voltage - Supply 2.375V ~ 3.465V
Temperature Range - Operating -40°C ~ 70°C
Mounting Type Surface Mount
Package / Case 16-LBGA, FCBGA
Supplier Device Package 16-FCBGA (4x4)
Base Product Number NBSG14
Standard Package 100 pcs
MSL Level 3 (168 Hours)
REACH Status REACH Unaffected
ECCN 3A001A11B
HTSUS 8542.39.0001
Win Source Part Number 719731-NBSG14BA
Ultra Librarian 3D Model Ultra Librarian NBSG14BA CAD Model

Description

ON Semiconductor NBSG14BA: A High-Performance Signal Gateway Solution

The NBSG14BA from ON Semiconductor is a remarkable solution for high-speed signal processing applications. This monolithic device incorporates a Serial RapidIO®-capable SerDes (Serializer/Deserializer) function, which is designed to deliver exceptional performance and reliability for a wide range of industrial and communication applications.

Key Features

  • High Data Rate: The NBSG14BA is capable of handling data rates up to 3.125 Gbps, making it suitable for high-speed data transmission requirements.
  • Low Power Consumption: Designed with power efficiency in mind, this device operates with a minimal power draw, which is crucial for energy-sensitive designs.
  • Differential Signaling: It uses differential CML data inputs and outputs, which provides noise immunity and improves signal integrity over long distances or in electrically noisy environments.
  • Programmable Functions: The device features programmable functions such as input equalization and output pre-emphasis, allowing fine-tuning for various application requirements.
  • Flexibility: The NBSG14BA's 2:1 multiplexer and 1:2 demultiplexer functionality offer design flexibility, making it a versatile choice for system architects.

Applications

The ON Semiconductor NBSG14BA is ideally suited for a variety of applications, including but not limited to:

  • Backplane interfacing
  • Base station development
  • High-speed networking equipment
  • Data center infrastructure
  • Telecommunications systems

Quality and Reliability

ON Semiconductor is known for its commitment to quality, and the NBSG14BA is no exception. It is manufactured using advanced semiconductor processes, ensuring high reliability and performance consistency. The device is also characterized for operation from -40°C to +85°C, making it suitable for industrial temperature ranges.

With its combination of high-speed capabilities, low power consumption, and robust design, the NBSG14BA from ON Semiconductor is an excellent choice for designers looking to incorporate a reliable SerDes solution into their high-performance systems.
