ON Semiconductor MC34071DR2G Operational Amplifier

The MC34071DR2G is a high-performance operational amplifier manufactured by ON Semiconductor. This op-amp is designed to offer a combination of precision, low power consumption, and wide bandwidth, making it suitable for a variety of electronic applications. The device features a single amplifier per package, which provides designers with the flexibility to use multiple units in complex circuits or to keep their designs simple and compact.

Key Features

• Single Supply Operation: The MC34071DR2G is capable of operating from a single supply voltage, which simplifies power supply design and is ideal for battery-operated equipment.
• Wide Bandwidth: With a bandwidth of 4.5 MHz, this op-amp can handle a range of signals, making it suitable for audio processing, filter circuits, and more.
• Low Input Offset Voltage: The device has a low input offset voltage, which improves accuracy in precision applications.
• Extended Temperature Range: The operational amplifier operates over an extended temperature range, ensuring reliability in varying environmental conditions.
• High Slew Rate: Its high slew rate allows the op-amp to respond quickly to changes in input signals, making it ideal for fast signal processing applications.

Applications

The MC34071DR2G operational amplifier is versatile and can be used in a wide array of applications. It is particularly well-suited for:

• Instrumentation amplifiers
• Audio processing circuits
• Active filters
• Signal conditioning
• Analog-to-digital converters
• General-purpose amplification

Package and Quality

The MC34071DR2G comes in an SOIC-8 package, which is a small-outline integrated circuit with 8 pins. This compact package is ideal for space-constrained applications. ON Semiconductor is known for its commitment to quality, and this product is no exception. It is designed to meet high standards of performance and reliability.
