Products specifications Report Issue?

Categories RF/IF and RFID
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Purpose Modulator/Demodulator
Frequency 300MHz
RF Type FM
Case / Package 14-SOIC
Win Source Part Number 003342-MC1496DR2G
Popularity Medium
Supply and Demand Status Sufficient
Application Field Used in Sensing & Instrumentation, Industrial
Ultra Librarian 3D Model Ultra Librarian MC1496DR2G CAD Model

Description

ON Semiconductor MC1496DR2G Balanced Modulator/Demodulator IC

The ON Semiconductor MC1496DR2G is a versatile integrated circuit designed for balanced modulation and demodulation applications. This monolithic transistor array provides excellent performance in a wide range of communication systems, including amplitude modulation (AM), frequency modulation (FM), phase modulation (PM), and double sideband suppressed carrier (DSB-SC) modulation schemes.

The device features a well-designed structure that includes a double-balanced mixer and a carrier suppression circuitry, which ensures minimal unwanted signal distortion and high isolation between the ports. The MC1496DR2G is capable of operating over a wide frequency range, making it suitable for both audio and RF applications.

Constructed using ON Semiconductor's high-quality bipolar technology, the MC1496DR2G boasts a robust design that ensures reliability and stability. The IC comes in a compact SOIC-14 package, which is conducive to space-saving on printed circuit boards and is ideal for automated surface mount assembly processes.

Key specifications of the MC1496DR2G include:

  • Supply Voltage Range: 4.5V to 8V
  • Low Distortion Characteristics
  • High Carrier Suppression: -65 dB typical
  • Wide Dynamic Range
  • Adjustable Gain and Balance

The MC1496DR2G is designed to be highly flexible, with external components allowing for adjustments in gain and balance, which can be tailored to specific application requirements. This adaptability makes it an excellent choice for designers who need a reliable modulator/demodulator that can be fine-tuned for optimal performance.

Applications for the MC1496DR2G include, but are not limited to, synchronous detectors, product detectors, phase detectors, frequency doublers, and modulators/demodulators for various forms of analog modulation. With its proven design and ON Semiconductor's commitment to quality, the MC1496DR2G stands out as a solid choice for engineers and designers looking for a dependable component for their modulation and demodulation needs.

For further information, datasheets, and support, customers are encouraged to visit ON Semiconductor's official website or contact their local sales representative.
