The MBRS360BT3G from ON Semiconductor is a robust Schottky barrier rectifier, designed for high-efficiency power management applications. This surface-mount device is packaged in a compact SMB package, making it suitable for space-constrained applications without compromising performance.

Key Features

• Voltage Rating: The rectifier has a maximum repetitive peak reverse voltage of 60V, facilitating its use in a wide range of electronic circuits.
• Forward Current: It boasts a high forward current rating of 3A, which is ideal for handling moderate power requirements efficiently.
• Low Forward Voltage Drop: With a low forward voltage drop, this component ensures minimal power loss during operation, enhancing overall system efficiency.
• High Surge Capability: The MBRS360BT3G can withstand high surge currents, making it suitable for applications that experience transient overloads.
• Temperature Range: This device operates over a broad temperature range from -65°C to 150°C, allowing for use in extreme environmental conditions.
• Guard Ring Die Construction: The guard ring die construction provides enhanced reliability through transient protection, thus extending the lifespan of the rectifier and the end product.

Applications

ON Semiconductor's MBRS360BT3G is highly versatile and can be used in a variety of applications, including:

• Power supply units
• DC-DC converters
• Free-wheeling diodes in converters and motor control circuits
• Automotive applications
• Reverse battery protection
• Portable devices and battery charging circuits

Environmental and Quality Certifications

The MBRS360BT3G is compliant with RoHS and Halogen-Free standards, reflecting ON Semiconductor's commitment to environmental sustainability. Additionally, it is designed to meet the rigorous demands of the automotive industry, with certifications that ensure reliability and performance under harsh conditions.
