Products specifications

Categories Discrete Semiconductor Products
Manufacturer ON Semiconductor
Packaging Reel - TR
Status Active
Diode Type Schottky
Voltage - DC Reverse (Vr) (Max) 40V
Current - Average Rectified (Io) 1A
Voltage - Forward (Vf) (Max) @ If 550mV @ 1A
Speed(Frequency) Fast Recovery = 200mA (Io)
Current - Reverse Leakage @ Vr 500μA @ 40V
Mounting SMD (SMT)
Case / Package SOD-123FL
Operating Temperature - Junction -55°C to 125°C
Win Source Part Number 104971-MBR140SFT3G
Ultra Librarian 3D Model Ultra Librarian MBR140SFT3G CAD Model

Description

MBR140SFT3G from ON Semiconductor is a single rectifier diode commonly considered for power conversion, reverse-polarity protection, output rectification, and general low-voltage switching supply designs. In practical applications, engineers may evaluate this device for compact consumer electronics, industrial control boards, automotive-adjacent power paths, and DC-DC conversion stages where efficient rectification and dependable sourcing are important. Its positioning within the single-rectifier category makes it relevant for designs that need a widely recognized manufacturer part with established market familiarity. Because the lifecycle status provided here is unknown, design teams should treat long-term availability as unconfirmed and verify current manufacturer guidance before locking it into new programs. RoHS compliance information is also not available in the provided data, so environmental compliance should be confirmed through the latest datasheet, product page, or formal manufacturer documentation. For sustaining engineering, procurement should validate stock, date codes, and compliance records before purchase.
