Products specifications

Categories Integrated Circuits
Manufacturer ON Semiconductor
Packaging Tube
Logic Type Inverter
Number of Inputs 6
Features Schmitt Trigger
Supply Voltage (V) 2V ~ 3.6V
Current - Quiescent (Maximum) 10μA
Current - Output High, Low 24mA, 24mA
Logic Level - Low 0.4V ~ 0.6V
Logic Level - High 1.7V ~ 2.2V
Max Propagation Delay at V, Max CL 6.5ns at 3.3V, 50pF
Temperature Range - Operating -40°C ~ 85°C
Mounting Style SMD
Supplier Device Package 14-SOIC
Manufacturer Package 14-SOIC
Family Part Number 74LCX14
Manufacturer Pack Quantity 1,100
MSL Level 1 (Unlimited)
Win Source Part Number 1132344-74LCX14M
Manufacturer Homepage www.fairchildsemi.com
Popularity Medium
Supply and Demand Status Limited
Application Field Used in Industrial
Ultra Librarian 3D Model Ultra Librarian 74LCX14M CAD Model

Description

ON Semiconductor 74LCX14M Low Voltage Hex Inverter

The 74LCX14M is a high-performance, low-voltage hex inverter with Schmitt-trigger inputs, manufactured by ON Semiconductor. This integrated circuit is designed to be used in 3.3V LVTTL/LVCMOS systems while maintaining 5V tolerant inputs. The 74LCX14M is ideal for interfacing with high-speed communication ports, microprocessors, and applications requiring voltage translation from 5V to 3.3V without the need for external components.

Featuring a robust design, the 74LCX14M provides optimal signal integrity with its Schmitt-trigger action at all inputs, which makes the circuit tolerant to slower input rise and fall times. This characteristic is particularly beneficial in applications where noise is present, ensuring the outputs are glitch-free during voltage transitions. The inputs can also handle 5V signals without damage, making this device suitable for mixed-voltage environments.

One of the key advantages of the 74LCX14M is its low power consumption. The device incorporates power-down high impedance inputs and outputs, which significantly reduces the power usage when not in active operation. Additionally, the 74LCX14M supports a wide data bandwidth, which provides higher data throughput and reduces signal delay, enhancing overall system performance.

The 74LCX14M is supplied in a compact SOIC-14 package, making it easy to integrate into a variety of printed circuit board designs. Its small form factor is beneficial for space-constrained applications without compromising functionality or electrical performance.

ON Semiconductor's commitment to quality ensures that the 74LCX14M meets strict industry standards for reliability and performance. This device is fully specified for hot insertion and is characterized for performance from -40°C to +85°C, making it suitable for industrial and commercial temperature ranges.

In summary, the 74LCX14M from ON Semiconductor is a versatile, low-voltage hex inverter that offers robust performance with 5V tolerant inputs. Its low power consumption, high-speed operation, and noise immunity make it an excellent choice for a wide range of applications requiring reliable logic level conversions and signal conditioning.
