XC5A-2082-1

Part No XC5A-2082-1
Manufacturer Omron
Catalog Backplane Connectors
Description CONN DIN PLUG 20POS PCB RA GOLD / 20 Position Din Connector Plug, Male Pins Gold Through Hole, Right Angle
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Connectors, Interconnects - Backplane Connectors - DIN 41612
Mfr Omron Electronics Inc-EMC Div
Series XC5
Package Tray
Connector Type Plug, Male Pins
Number of Positions 20
Number of Positions Loaded All
Pitch 0.100" (2.54mm)
Number of Rows 2
Style B
Mounting Type Through Hole, Right Angle
Termination Solder
Contact Finish Gold
Contact Finish Thickness 16.0µin (0.41µm)
Temperature Range - Operating -55°C ~ 125°C
Current Rating (Amps) 2A
Material Flammability Rating UL94 V-0
Material - Insulation Polybutylene Terephthalate (PBT) , Glass Filled
Base Product Number XC5A
Standard Package 80
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8536.69.4040
Win Source Part Number 1338989-XC5A-2082-1
Ultra Librarian 3D Model Ultra Librarian XC5A-2082-1 CAD Model

Description

The 1154268 is a 20-position DIN 41612 backplane connector designed for use in high-density applications. It has a pitch of 0.100" and is a plug with male pins.

  • Pitch: 0.100"
  • Positions: 20
  • Connector Type: DIN 41612 backplane connector
  • Connector Style: Plug with Male Pins
  • Rows: 2
  • Contact Finish: Gold with a thickness of 16.0µin
  • Contact Material: Polybutylene terephthalate (PBT) with glass filling
  • Current Rating: 2A
  • Operating Temperature Range: -55°C to 125°C
  • RoHS Compliant: Yes
  • Style: B
  • Loaded: All positions
