Product Overview: NXP TJA1057GT/3J

The TJA1057GT/3J is a high-performance, standalone CAN transceiver from NXP Semiconductors that offers a robust interface between a Controller Area Network (CAN) protocol controller and the physical two-wire CAN bus. Designed for high-speed automotive networking applications, the TJA1057GT/3J is an essential component for ensuring reliable data transmission in complex electronic systems found in modern vehicles.

Key Features

• High-Speed CAN Interface: Supports ISO 11898-2 and ISO 11898-5 standards for high-speed CAN applications up to 1 Mbps.
• Silent Mode: In silent mode, the TJA1057GT/3J can monitor CAN communication on the bus without influencing it, making it ideal for diagnostic equipment.
• Low-Power Mode: An integrated low-power mode helps reduce power consumption when the network is idle or when the system is in standby.
• Transceiver Status Reporting: The device provides feedback on the state of the CAN bus to assist in fault diagnosis and system monitoring.
• Robustness: Enhanced Electrostatic Discharge (ESD) protection ensures resilience in the harsh electrical environments found in automotive applications.

Applications

The TJA1057GT/3J is ideal for a wide range of applications within the automotive sector, including:

• Powertrain systems
• Chassis control modules
• Advanced driver-assistance systems (ADAS)
• Infotainment systems
• Body control modules

Technical Specifications

The device is housed in an 8-pin SOIC package, providing a compact footprint for space-constrained applications. It is designed to operate over a wide range of temperatures, from -40°C to +125°C, making it suitable for the demanding conditions of automotive environments. The TJA1057GT/3J also features differential receiver with wide common-mode range for improved noise immunity.

Quality and Reliability

NXP is known for its commitment to quality and the TJA1057GT/3J is no exception. It is manufactured to meet the stringent requirements of the automotive industry, including compliance with the AEC-Q100 standard for automotive quality.
