Product Overview: SJA1000T/N1,118 by NXP

The SJA1000T/N1,118 is a stand-alone controller from NXP Semiconductors designed for handling the communication protocols over Controller Area Network (CAN). As a pivotal component in automotive and industrial networking, the SJA1000T/N1,118 is crafted to facilitate reliable data transmission and reception in environments where high-speed and error-resilient communication is crucial.

Key Features

• Compatibility: Fully compatible with the CAN 2.0B protocol specification, it supports both standard (11-bit identifier) and extended (29-bit identifier) frames, ensuring seamless integration into a wide range of CAN-based systems.
• Transfer Rate: Capable of high-speed data transfer rates of up to 1 Mbps, this controller is ideal for applications requiring fast and efficient communication.
• Message Handling: It includes 64-byte receive and transmit FIFO buffers, which help to manage incoming and outgoing messages efficiently.
• Error Detection: Equipped with advanced error detection and confinement capabilities, the SJA1000T/N1,118 ensures the integrity of data transmitted over the network.
• Operating Modes: The device offers several operation modes including normal, listen-only, self-test, and sleep modes, allowing for flexibility in various application scenarios.

Applications

The versatility of the SJA1000T/N1,118 makes it suitable for a broad spectrum of applications, particularly in the automotive sector for onboard diagnostics, in-vehicle networks, and body control. It is also extensively used in industrial automation systems, medical equipment, and any other systems where a robust and reliable CAN network is required.

Package and Mounting

The controller comes in a 28-pin, plastic SO package, designated as TSSOP28, which is suitable for surface-mount technology (SMT). This compact form factor ensures that it occupies minimal space on a printed circuit board (PCB) while providing excellent thermal and electrical performance.

Quality and Reliability

NXP's commitment to quality means that the SJA1000T/N1,118 is manufactured to the highest standards. The device is designed to withstand the harsh conditions of automotive and industrial environments, ensuring long-term reliability and performance.

Overall, the SJA1000T/N1,118 is a robust and feature-rich CAN controller that offers a reliable solution for data communication in critical systems where performance and durability are paramount.
