Introducing the NXP PTN3460BS/F2 DisplayPort to LVDS Bridge

The NXP PTN3460BS/F2 is a highly versatile and efficient solution designed for enabling the conversion of DisplayPort signals into Low Voltage Differential Signaling (LVDS). This IC is perfect for developers and manufacturers looking to bridge the gap between newer digital video interfaces and traditional LVDS displays. It is an ideal choice for a wide range of applications, including notebooks, ultrabooks, desktop monitors, and TVs that require a seamless integration of modern video sources with established display technologies.

Key Features

• DisplayPort to LVDS Conversion: The PTN3460BS/F2 effortlessly converts DisplayPort signals into LVDS, ensuring compatibility with legacy display panels.
• High Resolution Support: It supports high-resolution video input, making it suitable for advanced multimedia applications.
• Embedded MCU: An integrated microcontroller provides flexible control and configuration, enabling a tailored solution for specific display requirements.
• EDID Management: The device can store EDID information with the help of an integrated non-volatile memory, simplifying the display detection and selection process.
• Power Management: Advanced power management features ensure energy efficiency, reducing power consumption for battery-powered devices.

Applications

The PTN3460BS/F2 is suitable for a diverse set of applications where the interface between DisplayPort and LVDS is required. It is particularly useful in:

• Notebook and Ultrabook PCs
• Desktop Monitors
• Industrial Displays
• Televisions
• Digital Signage

Design and Integration

Designed with simplicity in mind, the PTN3460BS/F2 comes in a compact HVQFN56 package, which makes it easy to integrate into various designs without occupying significant board space. Its low power consumption and minimal external component requirements contribute to a cost-effective and straightforward design process, helping manufacturers to bring products to market more quickly and efficiently.

With the PTN3460BS/F2, NXP continues to demonstrate its commitment to providing innovative solutions that bridge the gap between legacy and cutting-edge technologies, ensuring a smooth transition for the evolving electronics market.
