The P82B96TD,118 is a high-quality I²C-bus extender from NXP Semiconductors designed to provide significant improvements in I²C-bus performance and flexibility. This device allows the I²C-bus to interface with a range of different voltage levels and extends the bus length without compromising on the speed and integrity of the data transmission.

Key Features

• Extended Bus Length: The P82B96TD,118 allows for extended I²C-bus lengths, enabling devices to communicate over greater distances without signal degradation.
• Increased Fan-Out: With this bus extender, more devices can be connected to the I²C-bus, thus increasing the fan-out capability of the bus.
• Voltage Level Translation: It provides a seamless interface between systems that operate at different voltage levels, making it ideal for multi-voltage systems.
• High Noise Immunity: The device is designed to have a high immunity to electrical noise, which is crucial for maintaining signal integrity in noisy environments.
• Compatibility: It is fully compatible with the I²C-bus standard and can be used with standard I²C-bus devices and multiple P82B96 devices in a system.

Applications

The P82B96TD,118 is versatile and can be employed in a wide array of applications. It is particularly useful in:

• Industrial control systems
• Automotive networks
• Home entertainment systems
• Data communication systems
• Building automation

Technical Specifications

Some of the technical highlights of the P82B96TD,118 include:

• Operating Voltage Range: 3.0 V to 12 V
• Two-wire serial interface
• 400 kHz I²C-bus operation
• Low standby current
• SOIC-8 packaging for easy integration

With its robust feature set and NXP's commitment to quality, the P82B96TD,118 is an excellent choice for designers looking to enhance their I²C-bus systems' range, reliability, and scalability.
