The NXP P82B715PN is a versatile I²C-bus extender designed to provide a robust and efficient solution for extending the communication distance between I²C-bus devices. This powerful component allows for significant extension of the I²C-bus by buffering both the data (SDA) and the clock (SCL) lines, enabling the I²C-bus to interface with longer cables without signal degradation.

Key Features

• Extended I²C-bus Operating Range: The P82B715PN allows for an extended I²C-bus length, facilitating communication over greater distances without compromising signal integrity.
• High Noise Immunity: With its robust design, the device is highly resistant to electrical noise, making it suitable for use in electrically noisy environments.
• Bidirectional Signal Transmission: The device supports bidirectional data transfer on the I²C-bus, ensuring seamless communication between I²C devices.
• Increased Fan-out: The P82B715PN can drive more I²C-bus devices than a standard I²C-bus buffer, thereby expanding the number of devices that can be connected on a single bus.
• Low Standby Current: It features a low standby current, which is beneficial for power-sensitive applications.

Applications

The NXP P82B715PN is ideal for a variety of applications that require reliable long-distance communication between I²C devices. These include:

• Industrial Control Systems
• Building Automation
• Automotive Networks
• Telecommunications Equipment
• Consumer Electronics

Technical Specifications

The P82B715PN operates across a wide voltage range and is compatible with standard I²C-bus protocols. Notable technical specifications include:

• Supply Voltage Range: 3.0V to 12V
• Compatible with Standard I²C-bus Modes
• Operating Temperature Range: -40°C to +85°C
• Packaging: DIP8, SO8

Overall, the NXP P82B715PN is an exceptional choice for system designers looking to enhance I²C-bus capabilities in terms of distance and connectivity. Its ability to maintain signal integrity over long cables and in noisy environments, combined with its ease of use, makes it a valuable addition to any I²C-bus application.
