Products specifications Report Issue?

Manufacturer NXP
Win Source Part Number 1185883-IP4221CZ6-S
Manufacturer Homepage www.nxp.com
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name IP4221CZ6-S
Introduction Date April 29, 2008
ECCN EAR99
Country of Origin China, Malaysia
Halogen Free Compliant
Estimated EOL Date Obsolete / End of life
Ultra Librarian 3D Model Ultra Librarian IP4221CZ6-S CAD Model

Description

Product Overview: IP4221CZ6-S from NXP

The IP4221CZ6-S is a versatile ESD protection device designed by NXP Semiconductors, tailored to safeguard high-speed data lines and other sensitive electronic circuits from electrostatic discharge (ESD) and other transient voltage events. This component is a crucial element for maintaining the integrity and longevity of modern electronic systems found in a wide array of applications, from consumer electronics to industrial automation.

Key Features

  • ESD Protection: The device offers robust ESD protection up to 8 kV contact discharge as per the IEC 61000-4-2 standard, ensuring that your sensitive electronic components are shielded from the most common electrostatic events.
  • Low Clamping Voltage: Its low clamping voltage minimizes the stress on the protected component during a transient event, thereby enhancing the overall protection level.
  • Low Capacitance: With a low loading capacitance of just 1.5 pF, the IP4221CZ6-S is ideal for protecting high-speed data lines without significantly affecting signal integrity.
  • Ultra-Small Package: Housed in an ultra-small leadless 6-pin package (DFN2020-6), this device saves valuable board space and is suitable for space-constrained applications.
  • Multiple Application Support: This protection device is suitable for USB 2.0, HDMI, Ethernet, and other high-speed data interfaces, providing a versatile solution for a broad range of electronic devices.

Applications

The IP4221CZ6-S is designed for application in a variety of products, including but not limited to:

  • Smartphones and other portable devices
  • Computers and peripherals
  • Audio and video equipment
  • Set-top boxes and digital TVs
  • Networking and telecommunication systems

Reliability and Quality

NXP Semiconductors is committed to delivering high-quality and reliable products. The IP4221CZ6-S is produced with the stringent quality control processes for which NXP is known, ensuring that each device meets the highest standards of performance and durability.

Whether you're designing consumer electronics or industrial control systems, the IP4221CZ6-S from NXP provides the protection required to safeguard your sensitive circuits against the potentially damaging effects of ESD and other transient voltages, all while maintaining the functionality and signal integrity of your high-speed interfaces.
