Products specifications Report Issue?

Categories Discrete Semiconductor Products
Manufacturer NXP
Packaging Tube/Rail
Status Obsolete(EOL)
Diode Type Standard
Voltage - DC Reverse (Vr) (Max) 1500V (1.5kV)
Current - Average Rectified (Io) 10A (DC)
Voltage - Forward (Vf) (Max) @ If 1.8V @ 20A
Speed(Frequency) Standard Recovery >500ns, > 200mA (Io)
Reverse Recovery Time (trr) 600ns
Current - Reverse Leakage @ Vr 100μA @ 1300V
Mounting Through Hole
Case / Package TO-220AC
Operating Temperature - Junction 150°C (Max)
Win Source Part Number 201677-BY359-1500
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian BY359-1500 CAD Model

Description

The NXP BY359-1500 is a high-efficiency, fast recovery rectifier diode designed to provide reliable and robust performance in a wide range of applications. This diode is well-suited for use in high-frequency rectification and freewheeling operations in switched-mode power supplies, as well as in power conversion and management systems where efficiency is key.

Key Features

  • High Reverse Voltage: With a maximum repetitive peak reverse voltage (VRRM) of 1500 volts, the BY359-1500 is capable of handling high voltage applications with ease.
  • Fast Recovery Time: The fast recovery time of this diode minimizes power loss and improves efficiency, making it ideal for high-speed switching applications.
  • High Forward Surge Current: It features a high forward surge current capability, which ensures the diode can handle momentary overloads without failure.
  • Low Forward Voltage Drop: The low forward voltage drop (VF) characteristic of the BY359-1500 reduces power dissipation and improves thermal performance.
  • Robust Design: Encased in a SOD59 (TO220AC) package, this diode offers a robust design that is capable of withstanding harsh environments and mechanical stress.

Applications

The NXP BY359-1500 is suitable for a variety of applications, including:

  • Switched Mode Power Supplies (SMPS)
  • Power converters and inverters
  • Freewheeling diodes in motor control circuits
  • Snubber diodes
  • Energy storage systems

Technical Specifications

Parameter Value Repetitive Peak Reverse Voltage (VRRM) 1500 V Average Forward Current (IF(AV)) 3 A Forward Voltage Drop (VF) 1.3 V Recovery Time (trr) 500 ns

With its combination of high voltage capability, fast recovery time, and efficient performance, the NXP BY359-1500 is a reliable choice for engineers and designers looking to enhance the performance of their power management systems.
