74LVC1G14GV

Part No 74LVC1G14GV
Manufacturer NXP / Nexperia
Catalog Logic - Gates and Inverters
Description IC SNGL SCHMITT TRIG INV 5TSOP
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Nexperia USA Inc.
Packaging Reel - TR
Status Active
Logic Type Inverter
Number of Circuits 1
Number of Inputs 1
Features Schmitt Trigger
Supply Voltage - Operating 1.65 V to 5.5 V
Current - Quiescent (Max) 4μA
Current - Output High, Low 32mA, 32mA
Logic Level - Low 0.46 V to 1.58 V
Logic Level - High 1.14 V to 2.79 V
Max Propagation Delay @ V, Max CL 5ns @ 5V, 50pF
Temperature Range - Operating -40°C to 125°C
Mounting SMD (SMT)
Case / Package 5-TSOP
Dimension SC-74A, SOT-753
Win Source Part Number 095383-74LVC1G14GV
Introduction Date April 06, 2001
ECCN EAR99
Country of Origin Malaysia
Halogen Free Compliant
Estimated EOL Date 2025
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Sufficient
Ultra Librarian 3D Model Ultra Librarian 74LVC1G14GV CAD Model

Description

Product Overview: 74LVC1G14GV from NXP Semiconductors

The 74LVC1G14GV is a high-performance, single inverter gate with Schmitt-trigger input, designed by NXP Semiconductors. This advanced logic gate is part of the LVC family, which is renowned for its low-voltage operation and compatibility with 5V systems. The device is housed in a small, leadless very thin quad flat package (VQFN), making it ideal for space-constrained applications.

Key Features

  • High-Speed Performance: The 74LVC1G14GV operates at a voltage range of 1.65V to 5.5V, which allows for use in mixed-voltage environments and ensures compatibility with both 3.3V and 5V systems.
  • Low Power Consumption: This device is optimized for low power consumption, making it suitable for battery-powered and power-sensitive applications.
  • 5V Tolerant Inputs: Inputs can tolerate up to 5V, even when the device is powered off, providing additional protection and interfacing capabilities with higher voltage logic levels.
  • High Noise Immunity: The Schmitt-trigger action at all inputs makes the circuit highly tolerant to slower input rise and fall times, thus enhancing the noise immunity of the device.
  • ESD Protection: The 74LVC1G14GV includes input and output protection against electrostatic discharge (ESD), ensuring device reliability and longevity.
  • Leadless Package: The very thin quad flat non-leaded package (VQFN) is ideal for space-saving designs and for use in environments where PCB real estate is at a premium.

Applications

The 74LVC1G14GV is versatile and can be used in a variety of digital circuits. Its applications range from signal conditioning and pulse shaping to creating delay lines and oscillators. The device's high noise immunity makes it particularly useful in environments with electrical noise, such as industrial controls and automotive systems.

Quality and Reliability

NXP Semiconductors is known for its commitment to quality and the 74LVC1G14GV is no exception. It is manufactured to the highest standards, ensuring reliable performance in a wide range of operating conditions. This product is suitable for use in commercial, industrial, and automotive applications where robustness and reliability are crucial.

With its combination of high-speed operation, low power consumption, and robust protection features, the 74LVC1G14GV from NXP Semiconductors is an excellent choice for designers looking to optimize their digital logic circuits.
