Part No DS42MB100TSQ/NOPB
Manufacturer National Semiconductor (TI)
Catalog Interface - Signal Buffers, Repeaters, Splitters
Description DS42MB100 4.25 GBPS 2:1/1:2 CML
Datasheet
DS42MB100TSQ/NOPB Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category Integrated Circuits (ICs) - Interface - Signal Buffers, Repeaters, Splitters
Mfr National Semiconductor (TI)
Package Bulk
Product Status Active
Type Buffer, Multiplexer
Input CML
Output CML
Data Rate (Max) 4.25Gbps
Delay Time 1.0ns
Signal Conditioning Input Equalization, Output Pre-Emphasis
Voltage - Supply 3.135V ~ 3.465V
Temperature Range - Operating -40°C ~ 85°C
Mounting Type Surface Mount
Package / Case 36-WFQFN Exposed Pad
Supplier Device Package 36-WQFN (6x6)
Standard Package 1 pcs
HTSUS 0000.00.0000
Win Source Part Number 869585-DS42MB100TSQ/NOPB
Ultra Librarian 3D Model Ultra Librarian DS42MB100TSQ/NOPB CAD Model

Description

The National Semiconductor (TI) 869585-DS42MB100TSQ/NOPB is a Buffer/Multiplexer integrated circuit (IC).

  • Category: Interface - Signal Buffers, Repeaters, Splitters
  • Signal Type: CML
  • Data Rate: 4.25Gbps (Maximum)
  • Delay Time: 1.0ns
  • Supply Voltage: 3.135V to 3.465V
  • Operating Temperature: -40°C to 85°C
  • Package: 36-WFQFN Exposed Pad
  • Mounting Type: Surface Mount
  • Status: Active
