Same model may have multiple batches, images only for reference.
78615/8JC-R Real Image
Same model may have multiple batches, images only for reference.

78615/8JC-R

Part No 78615/8JC-R
Manufacturer Murata Power Solutions Inc.
Catalog Pulse Transformers
Description TRANSFORMER
Datasheet
78615/8JC-R Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Transformers
Manufacturer Murata Power Solutions Inc.
Series *
Dimension 0.354" L x 0.375" W (9.00mm x 9.52mm)
Height - Seated (Maximum) 0.250" (6.35mm)
Win Source Part Number 766185-78615/8JC-R
Popularity Medium
Supply and Demand Status Limited
Family Name 786J
Introduction Date January 01, 2000
ECCN EAR99
Country of Origin China
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian 78615/8JC-R CAD Model

Description

The 786J transformer from Murata Power Solutions Inc. is a high-quality component.

  • Height: 0.250" (6.35mm)
  • Dimension: 0.354" L x 0.375" W (9.00mm x 9.52mm)
  • Series Name: *
  • Family Name: 786J
