The Molex 53047-0810 is a PicoBlade connector header. The PicoBlade series is known for its compact size and secure connection, making it suitable for applications where space is limited. This header is designed for wire-to-board connections and offers a reliable solution for both signal and low-power applications. Its robust design ensures secure mating and long-lasting performance in various electronic devices.

Applications

• Consumer electronics (e.g., smartphones, tablets)
• Medical devices
• Industrial controls
• Robotics
• LED lighting

Features

• Ultra-Compact Size: Small footprint for high-density applications.
• Positive Locking: Ensures a secure and reliable connection, preventing accidental disconnections.
• Durable Construction: Made from high-quality materials for long-lasting performance.
• Polarization: Prevents incorrect mating, ensuring proper circuit connections.
• Surface-Mount Technology (SMT): Designed for automated assembly processes.

Benefits

• Space Savings: Enables high-density packaging in electronic devices.
• Reliable Connection: Provides a stable and consistent electrical connection.
• Ease of Assembly: Simplifies the manufacturing process.
• Reduced Downtime: Minimizes the risk of connection failures.
• Versatile Application: Suitable for a wide range of industries and applications.

Additional Details

The 53047-0810 is a surface-mount header, meaning it is designed to be soldered directly onto the surface of a printed circuit board. It is made from high-temperature thermoplastic, allowing it to withstand reflow soldering processes. The header is designed to mate with corresponding PicoBlade receptacles. Refer to the Molex datasheet for specific details on current rating, voltage rating, and mating compatibility.
