22288360 Molex, LLC
Same model may have multiple batches, images only for reference.

22288360

Part No 22288360
Manufacturer Molex, LLC
Catalog Rectangular Connectors
Description CONN HEADER 36POS .100 R/A TIN
Datasheet
22288360 Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Connectors, Interconnects
Manufacturer Molex, LLC
Series KK 42377
Packaging Bulk
Connector Type Header, Breakaway
Contact Type Male Pin
Pitch - Mating 0.100" (2.54mm)
Style Board to Board or Cable
Shrouding Unshrouded
Number of Positions 36
Number of Positions Loaded All
Number of Rows 1
Mounting Through Hole, Right Angle
Termination Solder
Fastening Type Push-Pull
Contact Length - Mating 0.244" (6.20mm)
Contact Length - Post 0.120" (3.05mm)
Insulation Height 0.098" (2.50mm)
Contact Shape Square
Contact Finish - Mating Tin
Contact Finish Thickness - Mating 100μin (2.54μm)
Contact Finish - Post Tin
Insulation Material Polyamide (PA), Nylon, Glass Filled
Material Flammability Rating UL94 V-0
Insulation Color Black
Contact Finish Thickness - Post 100μin (2.54μm)
Applications Automotive, General Purpose, Medical, Telecommunications
Win Source Part Number 761844-22288360
Popularity Medium
Supply and Demand Status Limited
Family Name 42377
Introduction Date July 07, 2010
ECCN EAR99
Country of Origin India, Mexico, United States of America
Halogen Free Not Compliant
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian 22288360 CAD Model

Description

The Molex 761844-22288360 is a connector header from the Molex KK 42377 series.

  • Positions: 36
  • Applications: Board to board or cable
  • Pitch-Mating: 0.100" (2.54mm)
  • Shrouding: Unshrouded
  • Insulation Material: Polyamide (PA), nylon, glass-filled
  • Contact Finish-Mating: Tin
  • Contact Finish Thickness-Mating: 100μin (2.54μm)
  • Applications: Automotive, general purpose, medical, and telecommunications
  • Popularity: Medium
  • Supply and Demand: Limited
