Same model may have multiple batches, images only for reference.
1300120113 Real Image
Same model may have multiple batches, images only for reference.

1300120113

Part No 1300120113
Manufacturer Molex, LLC
Catalog Cables, Wires Fiber Optic Cables
Description Cable Assembly Cord Set 1.83m 16AWG 12 POS Mini Change to 12 POS Mini Change F-M
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Cable Length 1.83 m
Color Yellow
Connector Type Circular
Connector Type A Receptacle
Connector Type B Connector
Contact Material Brass
Contact Plating Gold
Country of Origin US
Current Rating 5 A
Gender Female
Insulation Color Yellow
Insulation Material PVC
Length 1.8288 m
Max Current Rating 5 A
Max Operating Temperature 105 °C
Max Voltage Rating (DC) 600.6 kV
Min Operating Temperature -20 °C
Number of Conductors 2
Number of Pins 12
Orientation Straight
RoHS Compliant
Shielding Unshielded
Voltage Rating 600 V
Wire/Cable Gauge 16 AWG
Wire/Cable Type Round
Win Source Part Number 1217693-1300120113
Categories Cables, Wires Fiber Optic Cables
Manufacturer Molex, LLC
Popularity Medium
Supply and Demand Status Limited
Ultra Librarian 3D Model Ultra Librarian 1300120113 CAD Model

Description

The Molex 1217693-1300120113 is a high-quality yellow circular connector that is perfect for use with 12-pin cables manufactured by Molex.

  • Material: Brass
  • Voltage Rating: 600 V
  • Current Rating: 5 A
  • Cable Length: 1.83 m
  • Shielded: Yes
  • Orientation: Straight
  • RoHS Compliant: Yes
  • Popularity: Medium
  • Estimated Production Lead Time: 11 weeks
  • REACH: Unaffected
  • HTSUS: 8536.90.4000
  • Alternative Part Numbers: 130012-0113, 332020A01F060
  • Suitable For: Use in cables, wires, and fiber optic cables
