Product photo
Same model may have multiple batches, images only for reference.

Products specifications Report Issue?

Category RF and Wireless - RF Amplifiers
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Frequency 0Hz ~ 1GHz
P1dB 12.5dBm
Gain 25dB
Noise Figure 3.1dB
RF Type Cellular, PCN
Voltage - Supply 3.7V
Current - Supply 36mA
Test Frequency 1GHz
Mounting Type Surface Mount
Package / Case 4-SMD, Gull Wing
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8542.33.0001
Win Source Part Number 207729-MAR-8ASM+
Ultra Librarian 3D Model Ultra Librarian MAR-8ASM+ CAD Model

Description

The 207729-MAR-8ASM+ is an RF amplifier designed by Mini-Circuits.

  • Frequency Range: 0Hz to 1GHz
  • Gain: 25dB
  • Noise Figure: 3.1dB
  • P1dB: 12.5dBm
  • Supply Voltage: 3.7V
  • Current: 36mA
  • Package Type: 4-SMD, Gull Wing
  • Packaging: tape and reel
  • Standard Package Quantity: 1,000 pcs
  • Product Status: Active
  • Ensuring availability for: RF and wireless projects.
