ADTL1-12+ Real Image ADTL1-12+ real image ADTL1-12+ label picture
Same model may have multiple batches, images only for reference.
ADTL1-12+ Real Image ADTL1-12+ real image ADTL1-12+ label picture
ADTL1-12+ Real Image ADTL1-12+ real image ADTL1-12+ label picture
Same model may have multiple batches, images only for reference.

ADTL1-12+

Part No ADTL1-12+
Manufacturer Mini-Circuits
Catalog Balun
Description 1:1 CORE & WIRE TRANSFORMER, 20
Datasheet
ADTL1-12+ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - Balun
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Frequency Range 20MHz ~ 1.2GHz
Impedance - Unbalanced/Balanced 50 / 50Ohm
Phase Difference 4°
Insertion Loss (Max) 2.0dB
Return Loss (Min) 7.49dB
Package / Case 6-SMD, Flat Leads
Mounting Type Surface Mount
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8504.31.2000
Win Source Part Number 44577-ADTL1-12+
Ultra Librarian 3D Model Ultra Librarian ADTL1-12+ CAD Model

Description

Features and Benefits of ADTL1-12+

  • Compact design
  • Wide bandwidth capability
  • Robust construction

The ADTL1-12+ transformer is built to deliver exceptional performance with a compact design that supports wide bandwidth applications. Its robust construction ensures long-lasting reliability even in demanding environments.

Applications

  • Wireless communication
  • Network infrastructure
  • Instrumentation

Intended for use in wireless communication, network infrastructure, and instrumentation, the ADTL1-12+ is a versatile choice for various technical projects.
