ADC-26-52+ Real Image ADC-26-52+ real image
Same model may have multiple batches, images only for reference.
ADC-26-52+ Real Image ADC-26-52+ real image
ADC-26-52+ Real Image ADC-26-52+ real image
Same model may have multiple batches, images only for reference.

ADC-26-52+

Part No ADC-26-52+
Manufacturer Mini-Circuits
Catalog RF Directional Coupler
Description RF DIR COUPLER 10MHZ-500MHZ 6SMD
Datasheet
ADC-26-52+ Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Category RF and Wireless - RF Directional Coupler
Mfr Mini-Circuits
Package Tape & Reel
Product Status Active
Coupler Type Standard
Frequency 10MHz ~ 500MHz
Coupling Factor 26 ± 0.5dB
Applications General Purpose
Power - Max 2W
Return Loss 36.35dB
Package / Case 6-SMD, Flat Leads
Standard Package 1,000 pcs
MSL Level 1 (Unlimited)
ECCN EAR99
HTSUS 8548.00.0000
Win Source Part Number 709332-ADC-26-52+
Ultra Librarian 3D Model Ultra Librarian ADC-26-52+ CAD Model

Description

The ADC-26-52+ is an RF directional coupler.

  • Applications: General Purpose
  • Power Handling: 2W
  • Frequency Range: 10MHz to 500MHz
  • Coupling Factor: 26 ± 0.5dB
  • Return Loss: 36.35dB
  • Standard Package: 1,000 pcs
  • Package: Tape & Reel
  • Package Style: 6-SMD, flat leads
  • Manufacturer: Mini-Circuits
  • Product Status: Active
