Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Tube/Rail
Status Not For New Designs
Core Processor PIC
Part Core Size 8-Bit
Speed(Frequency) 20MHz
Number of I/O 22
Program Memory Size 14KB (8K x 14)
Program Memory Type FLASH
EEPROM Size 256 x 8
Data RAM Size 368 x 8
Supply Voltage - Operating 4 V to 5.5 V
Data Converters A/D 5x10b
Oscillator Type External
Temperature Range - Operating 0°C to 70°C (TA)
Case / Package 28-SOIC
Win Source Part Number 045852-PIC16F876-20/SO
Is this a common-used part? Yes
Popularity High
Supply and Demand Status Limited
Family Name PIC16F876
Introduction Date February 01, 2001
ECCN EAR99
Country of Origin Thailand
Halogen Free Compliant
Estimated EOL Date 2022
Ultra Librarian 3D Model Ultra Librarian PIC16F876-20/SO CAD Model

Description

The PIC16F876-20/SO from Microchip Technology is a versatile and powerful microcontroller that offers a robust suite of features for a wide range of applications. This member of Microchip's renowned PIC family of microcontrollers is designed to deliver high performance and reliability with low power consumption.

Key Features:

  • High-Performance RISC CPU: The device boasts a Reduced Instruction Set Computing (RISC) architecture, which enables the execution of most instructions in a single cycle, enhancing the overall speed and efficiency of the microcontroller.
  • Memory: It comes equipped with 14 KB of Flash program memory, 368 bytes of RAM, and 256 bytes of EEPROM data memory, providing ample space for complex programs and data storage.
  • Speed: The PIC16F876-20/SO operates at a speed of up to 20 MHz, ensuring swift processing and response times for time-sensitive tasks.
  • I/O and Peripherals: This microcontroller features 22 I/O pins, two capture/compare/PWM functions, and a synchronous serial port that can be configured as either 3-wire Serial Peripheral Interface (SPI) or the 2-wire Inter-Integrated Circuit (I²C™) bus.
  • Analog-to-Digital Converter: It includes a 10-bit, up to 8-channel Analog-to-Digital Converter (ADC), allowing the microcontroller to interface with analog sensors and devices.
  • Power Management: The PIC16F876-20/SO provides various power-saving modes, including Idle and Power-down modes, which significantly reduce power consumption when the device is not in full operation.
  • Package: The microcontroller is available in a 28-pin SOIC package, making it suitable for space-constrained applications.

Designed for ease of use and integration, the PIC16F876-20/SO is ideal for a broad spectrum of applications, such as industrial automation, consumer electronics, automotive systems, and more. Its robust instruction set, comprehensive peripheral support, and low power consumption make it an excellent choice for designers looking for a reliable and efficient microcontroller solution.

Whether you're developing a simple control system or a complex multi-faceted device, the PIC16F876-20/SO provides the flexibility and performance needed to meet the demands of your project.
