Microchip Technology's PIC16F1823-I/ML Microcontroller

The PIC16F1823-I/ML from Microchip Technology is a high-performance microcontroller that combines intelligent analog and digital peripherals with low-power features to cater to a wide range of applications. This 8-bit microcontroller is part of the PIC16F family and is particularly suitable for automation, consumer electronics, and embedded systems that require sophisticated control and monitoring capabilities.

Housed in a compact 16-pin QFN package, the PIC16F1823-I/ML is designed for space-constrained applications. It operates with an enhanced mid-range core, which provides efficient instruction execution of 1 to 2 cycles, ensuring a speedy response to real-time events. The device can run at a maximum frequency of 32 MHz, providing a robust processing backbone for complex tasks.

With 3.5 KB of flash memory and 128 bytes of EEPROM, the PIC16F1823-I/ML offers ample space for application code and data storage, allowing for in-circuit upgrades and parameter storage. The microcontroller includes 256 bytes of RAM, which is essential for efficient data manipulation and temporary storage during operation.

The device boasts an array of integrated features, including:

• Analog-to-Digital Converter (ADC) with up to 10-bit resolution, enabling precise analog signal measurement.
• Multiple communication interfaces such as I2C, SPI, and USART, which provide versatile connectivity options for peripherals and other microcontrollers.
• Two PWM channels that facilitate accurate control over motors and other actuators.
• A range of timers and comparators that support complex timing and control operations.

Furthermore, the PIC16F1823-I/ML supports enhanced power management with its Power-Saving Sleep mode, which significantly reduces power consumption when the device is idle. It also features Brown-out Reset (BOR) and Extended Watchdog Timer (WDT) to enhance system reliability and prevent unexpected failures.

Microchip's MPLAB® X Integrated Development Environment (IDE) fully supports the PIC16F1823-I/ML, offering a comprehensive development platform with advanced debugging tools. This, combined with a wide operating voltage range of 1.8V to 5.5V, makes it a versatile choice for designers who require a robust, low-power microcontroller for their next innovation.
