Products specifications Report Issue?

Win Source Part Number WS1196943-PAC1942T-2E/4MX
Win Source Part Number Cross
Manufacturer Microchip Technology
Category Integrated Circuits (ICs) Power Management (PMIC) Current Regulation/Management
Package Tape & Reel (TR) Cut Tape (CT)
Product Status Active
Function Current/Voltage Monitor
Sensing Method Low-Side
Accuracy ±1%
Voltage - Input 2.7V ~ 5.5V
Operating Temperature -40°C ~ 125°C (TA)
Ultra Librarian 3D Model Ultra Librarian PAC1942T-2E/4MX CAD Model

Description

The PAC1942T-2E/4MX is a high-precision, multi-channel energy and power monitoring device engineered by Microchip Technology, a leader in microcontroller, mixed-signal, analog, and Flash-IP solutions. This product is designed to accurately measure voltage, current, and power of supply rails that are below 32V. It is an ideal solution for applications requiring real-time energy monitoring, such as power management in computing systems, embedded systems, and industrial applications.

Key Features

  • Multi-Channel Monitoring: The PAC1942T-2E/4MX features two high-side current-sense amplifiers and four power-monitoring channels. This allows for simultaneous monitoring of multiple power rails, providing comprehensive insights into system power consumption.
  • High Accuracy: With its precision calibration, the device ensures high accuracy in power and energy measurements, which is critical for optimizing system power efficiency and performance.
  • Low Voltage Operation: Designed to operate at supply voltages below 32V, this device is well-suited for low-voltage applications where power conservation is essential.
  • Digital Interface: It comes with a full-duplex I2C interface, allowing for easy integration into existing designs and facilitating communication with microcontrollers or other digital systems.
  • Configurable Averaging: The PAC1942T-2E/4MX allows for configurable time averaging on all power and energy readings, enabling customized performance based on specific application needs.

Applications

The versatility of the PAC1942T-2E/4MX makes it suitable for a wide range of applications, including:

  • Server and enterprise power supply monitoring
  • Embedded systems and IoT devices
  • Industrial automation and control systems
  • Power management systems
  • Battery-powered devices

With its robust feature set and Microchip's reputation for reliability, the PAC1942T-2E/4MX is a smart choice for designers looking to enhance their power management capabilities and achieve greater energy efficiency in their products.
