MIC69302WR-EV

Part No MIC69302WR-EV
Manufacturer Microchip Technology
Catalog Evaluation Boards - Linear Voltage Regulators
Description Power Management Development Board / EVAL BOARD FOR MIC69302
Datasheet
Sample
Rohs State rohs
ECAD Module
Need Help

Products specifications Report Issue?

Categories Development Boards, Kits, Programmers
Manufacturer Microchip Technology
Channels per IC 1 - Single
Voltage - Output 0.5 V ~ 5 V
Output Current 3A
Voltage - Input 1.65 V ~ 5.5 V
Regulator Type Positive Adjustable
Operating Temperature Range -40°C ~ 125°C
Board Type Fully Populated
Supplied Contents Board(s)
Utilized IC / Part MIC69302
Win Source Part Number 788777-MIC69302WR-EV
Popularity Medium
Supply and Demand Status Balance
Family Name MIC69302WR
Introduction Date May 01, 2008
ECCN EAR99
Estimated EOL Date 2028
Ultra Librarian 3D Model Ultra Librarian MIC69302WR-EV CAD Model

Description

Product Overview: MIC69302WR-EV from Microchip Technology

The MIC69302WR-EV is a high-performance, adjustable output voltage regulator from Microchip Technology. This robust device is specifically designed to deliver up to 3A of output current while maintaining excellent line and load regulation. It is an ideal solution for a variety of demanding applications that require a stable and reliable power supply.

Key Features

  • High Output Current: Capable of delivering up to 3A of continuous output current, making it suitable for high-power applications.
  • Adjustable Output Voltage: Allows for a flexible output voltage range, which can be set to meet the specific needs of the target application.
  • Thermal Protection: Integrated thermal shutdown feature ensures the device operates within safe temperature limits.
  • High Accuracy: Provides tight load and line regulation, ensuring a stable output voltage even under varying operating conditions.
  • Low Dropout Voltage: Functions efficiently with a minimal difference between the input and output voltages, thereby reducing power loss and improving efficiency.

Applications

The MIC69302WR-EV is versatile and can be used in a wide array of applications, including:

  • Telecommunications
  • Networking equipment
  • Servers and data storage systems
  • Industrial control systems
  • High-performance computing

Product Evaluation

The MIC69302WR-EV evaluation board is designed to help engineers and designers quickly assess the features and performance of the MIC69302 voltage regulator. The evaluation board is fully assembled and tested, providing an immediate platform for device testing and facilitating an accelerated design process.

Quality and Reliability

Microchip Technology is known for its commitment to quality and reliability. The MIC69302WR-EV is manufactured with this same dedication, ensuring that it meets the high standards expected by industry professionals.

For detailed technical specifications, application notes, and support documentation, please visit Microchip Technology's official website or contact their customer support team.
