Products specifications Report Issue?

Categories Integrated Circuits
Manufacturer Microchip Technology
Packaging Reel - TR
Status Obsolete(EOL)
Type Hot Plug Controller
Number of Channels 6
Internal Switch(s) Both
Applications PCI Express
Features Latched Fault, SMBus, Thermal Limit, UVLO
Programmable Features Current Limit, Fault Timeout, Slew Rate
Supply Voltage - Operating 3 V to 3.6 V, 11 V to 13 V
Temperature Range - Operating 0°C to 70°C
Mounting SMD (SMT)
Case / Package 48-TQFP (7x7)
Win Source Part Number 208326-MIC2592B-2YTQTR
Ultra Librarian 3D Model Ultra Librarian MIC2592B-2YTQTR CAD Model

Description

Microchip Technology MIC2592B-2YTQTR Dual-Channel Power Distribution Switch

The MIC2592B-2YTQTR from Microchip Technology is a state-of-the-art dual-channel power distribution switch designed to enhance the performance and reliability of USB and other hot-swap applications. This integrated circuit is an essential component for managing power distribution with precision and efficiency, making it an ideal choice for a wide range of electronic devices.

Key Features

  • Dual Independent Channels: Each channel can control a separate load, providing flexibility and support for multiple devices.
  • Programmable Current Limiting: The current limit for each channel can be set independently, protecting the system from overcurrent conditions and ensuring safe operation.
  • Thermal Shutdown Protection: In-built thermal shutdown circuitry prevents overheating, enhancing the longevity and reliability of both the switch and the overall system.
  • Under-voltage Lockout (UVLO): This feature ensures that the switch remains off if the input voltage drops below a certain threshold, preventing erratic behavior or damage to connected devices.
  • Status Flag Outputs: The MIC2592B-2YTQTR provides real-time status feedback through flag outputs, allowing for immediate response to fault conditions.
  • Low Quiescent Current: The device is designed to have a minimal impact on power consumption when in standby mode, making it suitable for power-sensitive applications.

Applications

With its robust feature set, the MIC2592B-2YTQTR is well-suited for a variety of applications, including but not limited to:

  • USB hubs, peripherals, and docking stations
  • Hot-swap power supplies
  • Overcurrent and thermal protection circuits
  • Industrial controls
  • Portable consumer electronics

Technical Specifications

The device operates over a wide input voltage range and is available in a TQFN package. It is designed to meet the stringent requirements of modern electronic systems, offering a compact and reliable solution for power management.

Conclusion

The MIC2592B-2YTQTR from Microchip Technology is an advanced power switch that provides robust protection features and precise control, making it an indispensable component for designers looking to enhance the safety and efficiency of their power distribution systems.
