The MIC2298-15YML-TR is a high-performance, pulse-width modulation (PWM), white LED driver from Microchip Technology. Designed with precision and efficiency in mind, this integrated circuit is specifically tailored for driving high-brightness LEDs. It operates from a 2.5V to 10V input voltage, making it versatile for a wide range of applications, from portable devices to automotive lighting.

Key Features

• Adjustable Output Voltage: The device provides an adjustable output that can be set to drive LEDs in series, ensuring consistent brightness and improving efficiency.
• High Frequency Operation: With a switching frequency of up to 1.2MHz, the MIC2298-15YML-TR allows for the use of small external components, reducing the overall footprint and cost of the system.
• Integrated Switch: The built-in 1.2A switch minimizes the need for external components, simplifying design and enhancing reliability.
• Thermal Shutdown: Safety is a priority with the MIC2298-15YML-TR, featuring thermal shutdown protection that prevents damage from overheating.
• Dimming Capability: It supports both analog and PWM dimming, offering flexibility for controlling the brightness of the LEDs.

Applications

• Portable Devices
• Automotive Lighting
• LCD Backlighting
• General LED Illumination

Package and Availability

The MIC2298-15YML-TR comes in a compact 10-pin 3x3mm MLF® package, which is ideal for space-constrained applications. The device is available in tape and reel format, denoted by the "-TR" suffix, facilitating easy integration into automated manufacturing processes.

Conclusion

With its high efficiency, small form factor, and comprehensive protection features, the MIC2298-15YML-TR from Microchip Technology stands out as a robust solution for LED driving requirements across various industries. Its high level of integration and ease of use make it a go-to choice for engineers looking to optimize their lighting applications.
